Ice cream mini spoon Mold Auto production

Product information

  • Part Name: Ice cream mini spoon
  • Part Material: PS
  • Part Weight: 0.8g
  • Part Size: Length 90mm

Mould information:

  • Mould cavities: 32 cavities
  • Mould injection system: 1 tip hot runner
  • Mould steel: S136 steel with Hardness HRC 45-48
  • Suitable injection machine: 160T
  • Cycle time: 14s

This spoon Mold production automatically, the gate be cut inside mold during ejection, robot help to take out center runner, in this case, no need worker to break the gate by hand.

If you are interested in cutlery mold, welcome to send your inquiry to us.

Elaine Ruan / WhatsApp: +86 18257612359
